MS08-R300.H.2HD
Regular price
$650.00
Couldn't load pickup availability
Follow us on soical media to get the lastest news!!
8-Bay Mini Server Tower
.Supports NVMe/SAS/SATA III HDD
.Supports maximum 12 x 2.5"/3.5" hot-swap SSD drives (including 2 x 2.5" internal HDD)
.File server and NAS devices usage
.Supports 4 x full-height PCIe slots
.Supports maximum 4 x 80mm fans for excellent thermal performance
.High-efficiency 80 Plus Gold level redundant power supplies
.Supports magnetic lock in the front bezel for hardware security
Specifications | |
---|---|
M/B Form Factor | Micro-ATX (9.6" x 9.6"), Mini-ITX (6.7" x 6.7") |
Drive Bay | • External: slim ODD x 1, 2.5" hot-swap drive bays x 2 (optional), 2.5"/3.5" hot-swap drive bays x 8 • Internal: 2.5" x 2 or 3.5" x 1 (require to remove 2.5" HDD x 2) |
Power Supply | Supports: • 1U redundant PSU, 80 Plus Gold 300W • 1U single PSU, 80 Plus Gold 500W • 1U Flex PSU, 80 Plus Gold 315W |
Indicator | Power LED, LAN1/LAN2/LED, system LED, ID LED, HDD LED |
Front Control Panel | Power on/off, reset, USB3.0 x 2 |
Backplane Type-1 | • Host: Mini-SAS HD (SFF-8643) x 2 • HDD: SAS/SATA x 8 |
Backplane Type-2 | • Host: Mini-SAS HD (SFF-8643) x 2, OCuLink (SFF-8611) x 4 • HDD: SAS/SATA x 8 or SAS/SATA x 4 and NVMe SSD x 4 |
Cooling Fan | Supports: • Middle: 80 x 25mm PWM fans x 2, 4200RPM • Rear: 80 x 25mm PWM fans x 2, 3600RPM |
Expansion Slot | Full-height PCIe slots x 4 |
Material | • Material: SECC • Thickness: 1.0mm |
Product Dimensions (DxWxH; Chassis Only) | 480.3 x 169.95 x 339.95 (18.91" x 6.69" x 13.38") |
Package Dimensions (DxWxH) | 00630 x 450 x 310mm |
Weight (Chassis Only) | • Net weight: 10.37kg • Gross weight: 12.52kg |
Cubic Feet | 3.1 |
Container Information | Single packing with pallets: • 20': 240pcs • 40': 504pcs |
